Product specifications
San Ace 92W
Model No: 9WV0924P1H001
Frame material : Plastic
Rated voltage [V] : 24
Operating voltage range [V]: 20.4～26.4
Rated current [A] : 1.6
Rated input [W] : 38.4
Rated speed [min-1] : 8500
Max. airflow [m3/min] : 5.05
Max. airflow [CFM] : 178
Max. static pressure [Pa] : 385
SPL [dB(A)] : 64
Operating temperature[˚C]: -20～+60
Expected life[h] : 30000/60℃ （53000/40℃）
Mass [g] : 265
Sensor type : Pulse sensor
IP rating : IP68
PWM control function : Yes
Ribbed : Yes
- Sanyo Denki product -
