Product specifications
ERF4039
The ERF4039 antenna is an internal SMD GPS antenna.
The antenna requires a ground plane of 50 x 100 mm.
Also it is recommended to use a matching filter to tune the performance of the antenna.
The antenna can be used for applications such as, M2M, GPS and GLONASS.
Electrical Properties
Frequency Band: 1575.42 MHz
Nominal Impedance: 50 ohm
Polarization: Linear
V.S.W.R: 1.5
Gain: 1.5 dBi
Mechanical Properties
Antenna Type: Chip antenna
Mounting Method: SMD
Antenna Dimensions: 4 * 10 * 3 mm ± 0.3
Operating Temperature Range: -40°C~+105°C
Storage Temperature Range: -40°C~+105°C
