Product specifications
ERF4043
The ERF4043 Antenna is a 868 MHz antenna with a hinged design and a SMA (Male) connector.
The hinged design enables the antenna to be positioned at its most suitable angle with a maximum of 90°.
The antenna can also be used in these frequency bands: 2680 to 2820 MHz.
The antenna can be used for applications , such as M2M , GSM and IoT.
Electrical Properties
Frequency Band: 860 ~ 900 / 2680 ~ 2820 MHz
Nominal Impedance: 50 Ω
Polarization: Vertical
V.S.W.R:<3.0
Mechanical Properties
Antenna Type: External Antenna
Touch Type: Screw Type
Connector Type: SMA Male
Antenna Dimensions: 186 mm ± 0.5
Antenna Color: Black
Operating Temperature Range: -20°C~+60°C
Storage Temperature Range: -30°C~+70°C
