Product specifications
ERF4096
The ERF4096 antenna is a 868 MHz antenna with a SMA (Male) Right angle connector.
The antenna can also be used in the frequency range of 840 ~ 886 MHz / 1140 ~ 1330 MHz / 2500 ~ 2560 MHz .
The antenna can be used for applications , such as M2M, IoT , GSM and more.
Electrical Properties
Frequency Band: 842 ~ 886 / 1140 ~ 1330 / 2500 ~ 2560 MHz
Nominal Impedance: 50 Ω
Polarization: Linear
V.S.W.R: <2.5
Mechanical Properties
Antenna Type: External Antenna
Touch Type: Screw Type
Connector Type: SMA Male
Antenna Dimensions: 54.4 ± 1.5
Antenna Color: Black
Operating Temperature Range: -40°C~+85°C
Storage Temperature Range: -40°C~+85°C
