Product specifications
2JL01
433 MHz ISM Surface Mount Compact Ceramic Antenna
General Specification
Frequency: 433MHz/Sigfox/LoRa/LPWA/RFID/ISM
Mounting: Surface Mount Ceramic
Dimensions (mm): 5 x 3 x 0.5
Operating temperature: -40 °C to +85 °C
Antenna and electrical specifications
433 MHz ISM
Standards: ISM, LoRa
Frequency: 433-435
VSWR: ~1.5:1
Peak Gain (dBi): ~4.7
Impedance (Ohm): 50
Polarisation: Linear
Max. Input Power (W): 25
