Bluetooth® v5.0 Serial Adapter – Dual Mode RS232 – LM068
LM068-1100 - adapter only
LM068-1102 - adapter + DB9 male to male gender changer
LM068-1101 - adapter+ DB9 male to male gender changer + mini USB cable + power supply
LM068-1104 - Two adapters + DB9 male to male gender changer
LM068-1103 - Two adapters + DB9 male to male gender changer + mini USB cable + power supply
The LM068 is the world’s smallest Bluetooth® 5.0 serial adapter (RS232), providing a secure and reliable Bluetooth® 5.0 connection.
Designed to replace RS232 cables between a master (DTE) device and slave (DCE) devices such as printers, data loggers and digital signalling devices.
This standalone adapter incorporates a micro-controller unit with an 8 Mbit flash memory for running the application. The firmware controls the RS232 signals, including DTR / DSR handshaking and RTS / CTS flow control lines.
The AT Command set is used to change the configurations, plus the developer can also configure and modify the settings of a remote LM068 from a local LM068. Customised configurations and settings can be preloaded to the LM068, simplifying the manufacturing and testing process.
We also offer Bluetooth® Dual Mode applications, which can be customised to your specification. The module can be used as a bridge between Bluetooth® 5.0 and is backward compatible with 2.0, v2.1 and Bluetooth® v4.0, v4.1 devices, using our SPP to Serial Bridge application.
We also offer SPP with GAP Central and SPP or GAP Peripheral applications.
- LM Technologies product -
