How GNSS positioning techniques improve accuracy of outdoor devices - Quectel
November 2, 2023
GNSS has proven to be a valuable positioning technology but it has inherent weaknesses that hinder its effectiveness in certain scenarios, which are detailed in a whitepaper titled ‘How to achieve cm-accurate positioning for mass-market IoT devices', written by Florian Bousquet, Quectel Wireless Solutions.
Fundamentally, GNSS needs to be able to ‘see’ the sky, so it can receive the direct signal from the satellites. In a real-world environment, accessing a direct signal is not always possible, and it cannot be relied upon as the only solution to provide a device with accurate location at all times. These GNSS challenges and how to overcome limitations via techniques such as multi-band GNSS, real-time kinetic (RTK) positioning and dead reckoning (DR) can be explaned.
Multi-band GNSS can be utilized to mitigate the detrimental effects of multipath. The technology uses multiple frequency bands, typically combining generic L1 (GPS L1, Galileo E1, GLONASS G1 and BDS B1) and modernized L5 signals (GPS L5, Galileo E5a and BDS B2a). The rationale behind this approach lies in the distinct characteristics of different frequency bands. Quectel focuses on bands L1 and L5, other bands such as L2 exist. Receivers that support L2 typically have a higher cost of ownership that is not compatible with mass-market devices.
The GNSS technologies that can improve accuracy in outdoor devices
The L1 band is susceptible to multipath interference, whereas the L5 band exhibits superior multipath mitigation capabilities. By integrating both signals, the multi-band GNSS system can effectively discriminate between direct and reflected signals, enhancing the accuracy of positioning results. In addition to the advantages offered by the L5 signal characteristics, the implementation of multi-band signals can also help alleviate the adverse impact of ionospheric disturbances on positioning accuracy.
RTK is a technique designed to counteract signal errors in GNSS positioning. It utilizes a nearby reference station with known coordinates or a network of reference stations (also known as network RTK) to provide correction data in real-time via a carrier (cellular, broadcast radio, or satellite). The basic principle behind RTK is that it uses the carrier-phase differential technique to compensate for common errors from the satellites and atmosphere using the correction data. This approach significantly improves the GNSS accuracy to centimeter or decimeter level in open or semi-open environments.
Dead reckoning (DR) is a technique that provides continuous positioning even in the absence of GNSS signals. It relies on internal sensors (such as accelerometers and gyroscopes) and external sensors (such as odometers or speed pulses), to estimate the vehicle’s movement based on its initial position and subsequent changes in velocity, orientation, and position.
The underlying principle of DR is that even in situations where GNSS signals are weakened or unusable due to reflections or blockages, the vehicle’s motion can still be tracked by integrating data from these sensors over time. While DR does not provide absolute positioning, it can bridge GNSS signal gaps and offer reliable positioning estimates, making it valuable in scenarios where signal reflections or brief signal interruptions are common. Further detail plus information on popular outdoor connected IoT applications is contained in the paper.
Learn more about the possibilities with the multi-band GNSS modules, real-time kinetic (RTK) positioning and dead reckoning (DR):
