Product specifications
AIC1513 - 8-Channel Parallel High Voltage Driver IC - 20-pin SOP
PRODUCT OVERVIEW
The AIC1513 is a rigid, low-cost general purpose high voltage driver IC with 8 high voltage push-pull outputs. The device has been designed for harsh industrial applications and allows a wide application area. The outputs can drive capacitive and resistive loads such as piezoelectric transducers, electroluminescent devices and micro-mechanical actuators. The maximum operating voltage is 300V, and each output can handle currents up to 40 mA.
TYPICAL APPLICATIONS
• Drive of Capacitive Actuators
• Piezo Transducer Excitation
• Electro-Luminescent Displays
FEATURES
• Wide supply voltage range (30V to 300V)
• Output current per channel is 40mA
• Output rise time control by external resistance
• Serial or parallel input
• N-channel MOSFET outputs for reduced power consumption
- APEX Microtechnology product -
